| Model | T-1600MX |
|---|---|
| Exposing Method | External Drum |
| Image System | 825nm laser |
| Output Speed | 22 plates/hour at 1630mm × 1325mm / 2400dpi |
| Plate Sizes | Max: 1680mm × 1350mm; Min: 650mm × 550mm |
| Exposing Size | Max: 1680mm × 1336mm |
| Media Type | Positive/Negative Thermal CTP Plate or Non Chemical Plate |
| Plate Thickness | 0.15mm to 0.30mm or 0.27mm to 0.40mm (alternative) |
| Resolution | Standard: dual resolutions 2400dpi and 1200dpi or optional 2540dpi and 1270dpi. Variable high resolution option: maximum up to 10800dpi at fast scan direction. 12800DPI available upon requirement |
| Repeatability | ±0.01mm (continuous exposing for 4 times or above at 23℃ and 60% humidity) |
| Interface | Optical Fiber |
| Plate Loading | Semi automatic (alternative autoloader system) |
| Net Weight | 1800kg |
| Machine Size (W×L×H)mm | 2400 × 1430 × 1110 |
| Power Supply | 3 phase 380V, power consumption (peak value): 5.5KW |
| Operation Environment | Recommended temperature: 21-25℃; Allowed temperature: 15-30℃, humidity: <70%RH |
